Welding Symbol Reading Quiz

Name:

Date:

🔧 Part 1: Basic Welding Symbol Components

1. What are the three main parts of a welding symbol?

Reference line, arrow, and tail

Arrow, weld symbol, and dimensions

Reference line, arrow, and weld symbol

Tail, dimensions, and finish symbol

2. Where is the weld applied when the weld symbol appears BELOW the reference line?

On the arrow side of the joint

On the other side of the joint

On both sides of the joint

Inside the joint

3. What does a filled-in flag or triangle symbol at the junction mean?

Weld all around

Field weld

Backing required

Grind smooth

4. What does a circle around the junction of the reference line and arrow indicate?

Field weld

Weld all around

Backing strip

Root opening

⚡ Part 2: Weld Types and Symbols

5. Match each weld symbol with its name by writing the correct letter:

A. Fillet weld B. Groove weld C. Plug/Slot weld D. Spot weld

_____ Triangle symbol

_____ Square or V-shaped symbol

_____ Circle symbol

_____ Rectangle symbol

6. What information can be found in the tail of a welding symbol?

7. If you see dimensions like "1/4" to the left of a fillet weld symbol, what does this number represent?

📐 Part 3: Reading Welding Symbols

8. A welding symbol shows a fillet weld symbol below the reference line with "3/16" to the left of it. Describe this weld:

Weld type: _________________ Size: _________________ Location: _________________

9. List three safety considerations when reading and following welding symbols in the shop:

10. Why is it important for welders to accurately read and interpret welding symbols?

Welding Symbol Reading

Welding Symbol Reading Quiz

🔧 Part 1: Basic Welding Symbol Components

⚡ Part 2: Weld Types and Symbols

📐 Part 3: Reading Welding Symbols
